UltraTech Drain Guards
Keep Sediment And Other Pollutants From Entering The Water System With Ultra Drain Guard Catch Basin Inserts.
Stormwater pollution has become a major concern both locally and on a national level. Ultra-Drain Guards remove waste from stormwater before it can become a problem in the water system.
- Exceeds 80% sediment removal efficiency
- Helps comply with NPDES, 40 CFR 122.26 (1999) when used as Best Management Practice in Storm Water Pollution Prevention Plans.
- Designed for practical use in:
Construction Sites - capture eroded soil and wind-blown debris. Parking Lots, "Drive-Up" Retail Facilities - selected geotextiles collect oil, fuel and other contaminants that drip from cars. Industrial Facilities - keep oil and other contaminants from entering storm drains.
| ULTRA-DRAIN GUARD | |
|---|---|
| Oil & Sediment Model: 48" x 36" | Oil & Sediment Plus Model: 48" x 36" |
| Part# 9217: 48"L x 36"W x 18"H (1-Pack) | Part# 9219: 48"L x 36"W x 18"H (1-Pack) |
| Performance : Oil: Up to .87 gallons (3.5 L) Sediment: Up to 40 lbs. (18 kg) | Performance : Oil: Up to 1.38 gallons (5 L) Sediment: Up to 40 lbs. (18 kg) |
| The total water flow rate through the insert in new condition is in excess of 500 gpm. The bypass rate is approximately 700 gpm. | |
| Oil & Sediment Model: 60" x 60" | Oil & Sediment Plus Model: 60" x 60" |
| Part# 9356: 60"L x 60"W x 18"H (1-Pack) | Part# 9358: 60"L x 60"W x 18"H (1-Pack) |
| Performance : Oil: Up to 1.55 gallons (5.9 L) Sediment: Up to 40 lbs. (18 kg) | Performance : Oil: Up to 2.06 gallons (7.8 L) Sediment: Up to 40 lbs. (18 kg) |
| Weight: 2 lbs. (1 kg) | Weight: 3 lbs. (1.5 kg) |
| The total water flow rate through the insert in new condition is in excess of 900 gpm. The bypass rate is approximately 700 gpm. | |
| Trash & Debris Model | |
| Part# 9227: 48"L x 36"W x 18"H (1-pack) | |
| Weight: 1 lb. (0.5 kg) | |
| Performance - 1 cu. ft. (28 L) - before reaching bypass ports. | |
Many options / versions available. Please contact our office 1.888.548.3800 or sales@spillsupply.com
Please contact us for pricing on UltraTech Spill Containment Pallets.
